Materials, construction and design. |
|
||
| ||||||||||
|
|  MIL-M-45532B
Military
MIL-STD-105 -
Sampling Procedures and Tables for Inspection
by Attributes
MIL-STD-l09 -
Quality Assurance Terms and Definitions
DRAWINGS
Rock Island Arsenal
F7790723
Mount,
Tripod,
Machine
Gun,
M122
(Product drawings referenced in this specification form a part of Drawing
F7790723.)
PUBLICATIONS
Rock Island Arsenal
P7790723
-
Packaging Data Sheet for Mount, Tripod, Machine
Gun: M122
QE-G-DL7790723 -
Quality Engineering Data List for Mount, Tripod,
Machine Gun: M122
(Copies of specifications, standards, drawings and publications required
by suppliers in connection with specific procurement functions should be
obtained from the procuring activity or as directed by the contracting offi-
cer.)
3. REQUIREMENTS
* 3.1 First article. Requirements for submission of the first article
shall be as specified in the contract (see 6.1). Unless otherwise speci-
fied (see 6.1), the first article shall include the pilot pack (see 5.1).
3.2 Materials, construction and design. The tripod mount shall con-
form to the materials, construction and design requirments specified
herein, on Drawing F7790723, and in MIL-w-13855.
3.2.1 Front leg assembly. The front leg assembly shall be ertained
to the tripod head assembly by the bolt and shall pivot about the bolt
throughout the full range of travel without binding.
3.2.2 Left rear leg assembly. The left rear leg assembly shall be
retained to the tripod head assembly by the bolt and shall pivot about the
bolt throughout the full range of travel without binding.
3.2.2.1 Left sliding sleeve. The left sliding sleeve shall slide on
the left rear leg throughout the full range of travel without binding.
2
|
|
